1.Use high performance SMD LED,CRI>80/90
2.Aluminum heat sink and unique Die casting heat sink design ensures good heat dissipation.
3.LED source Osram or San'an can be optional.
4.Driver brand can be optional
5.Application: Direct replacement for luminaires with compact fluorecent lamps,general illumination,public areas,stairways,corridors,foyers,shops
Item No. | IBDL240 |
Wattage | 10W/20W/30W/40W/50W |
CRI | 80/90 |
CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
Beam angle | 50 degree |
Lumen | 1100lm/2200lm/3240lm/4300lm/5450lm |
Finish | Matt white trim |
IP rating | IP20 |
Material | Die-casting alu.trim and heatsink,PMMA lens |
Driver | Constant current remote LED driver included |
Product Size | Φ115*H65mm for 10W Φ140*H80mm for 20W Φ160*H85mm for 30W Φ198*H98mm for 40W Φ230*H102mm for 50W |
Cutout size | Φ100mm for 10W Φ125mm for 20W Φ145mm for 30W Φ180mm for 40W Φ215mm for 50W |
LED source | COB, Cree/Bridgelux |
Input Voltage | 220-240vac/100-240vac |
Installation | Suitable for 5-18mm thick ceiling board |
Diming | Non Dim/Triac/0-10V/Dali Dim |
