1.USe high performance LED,CRI>80/90
2.Aluminum heat sink and unique Die casting heat sink design ensures good heat dissipation.
3.LED source Osram or San'an can be optional.
4.Driver brand can be optional
5.Application: Direct replacement for luminaires with compact fluorecent lamps,general illumination,public areas,stairways,corridors,foyers,shops
Item No. | IBSP134 |
Adjustable | Yes |
Wattage | 5W/9W/12W/15W/30W |
CRI | 80/90 |
CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
Beam angle | 15/24/38 |
Lumen | 475lm/855lm/1236lm/1545lm/3090lm |
Finish | Matt white trim |
IP rating | IP20 |
Material | Die-casting alu.trim and heatsink,PMMA lens |
Driver | Constant current remote LED driver included |
Product Size | Φ68*H68mm for 5W Φ86*H92mm for 9W Φ86*H100mm for 12W Φ107*H110mm for 15W Φ138*H130mm for 30W |
Cutout size | Φ55mm for 5W Φ75mm for 9W Φ75mm for 12W Φ95mm for 15W Φ120mm for 30W |
LED source | COB, CREE/BRIDGELUX |
Input Voltage | 220-240vac/100-240vac |
Diming | Non Dim/Triac/0-10V/Dali Dim |
