1.USe high performance LED,CRI>80/90
2.Aluminum heat sink and unique Die casting heat sink design ensures good heat dissipation.
3.LED source Osram or San'an can be optional.
4.Driver brand can be optional
5.Application: Direct replacement for luminaires with compact fluorecent lamps,general illumination,public areas,stairways,corridors,foyers,shops
Item No. | IBSP222 |
Adjustable | No |
Wattage | 10W/15W/25W |
CRI | 80/90 |
CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
Beam angle | 15/24/36/60 |
Lumen | 1000lm/1500lm/2500lm |
Finish | Matt white trim |
IP rating | IP20/IP65 |
Material | Die-casting alu.trim and heatsink,PMMA lens |
Driver | Constant current remote LED driver included |
Product Size | Φ85*H55mm for 10W Φ105*H63mm for 15W Φ130*H77mm for 25W |
Cutout size | Φ75mm for 10W Φ95mm for 15W Φ120mm for 25W |
LED source | COB, CREE/BRIDGELUX |
Input Voltage | 220-240vac/100-240vac |
Diming | Non Dim/Triac/0-10V/Dali Dim |
