1.USe high performance LED,CRI>80/90
2.Aluminum heat sink and unique Die casting heat sink design ensures good heat dissipation.
3.LED source Osram or San'an can be optional.
4.Driver brand can be optional
5.Application: Direct replacement for luminaires with compact fluorecent lamps,general illumination,public areas,stairways,corridors,foyers,shops
Item No. | IBSP130 |
Adjustable | Yes |
Wattage | 5W/7W/8W/10W/18W/25W |
CRI | 80/90 |
CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
Beam angle | 15/24/38 |
Lumen | 525lm/735lm/840lm/1050lm/1890lm/2625lm |
Finish | Matt white trim |
IP rating | IP20 |
Material | Die-casting alu.trim and heatsink,PMMA lens |
Driver | Constant current remote LED driver included |
Product Size | Φ67*H83mm for 5W Φ67*H100mm for 8W Φ88*H87mm for 7W Φ88*H89mm for 10W Φ88*H113mm for 18W Φ108*H112mm for 18W Φ108*H132mm for 25W |
Cutout size | Φ55mm for 5W Φ55mm for 8W Φ75mm for 7W Φ75mm for 10W Φ75mm for 18W Φ95mm for 18W Φ95mm for 25W |
LED source | COB, CREE/BRIDGELUX |
Input Voltage | 220-240vac/100-240vac |
Diming | Non Dim/Triac/0-10V/Dali Dim |
