1.USe high performance LED,CRI>80/90
2.Aluminum heat sink and unique Die casting heat sink design ensures good heat dissipation.
3.LED source Osram or San'an can be optional.
4.Driver brand can be optional
5.Application: Direct replacement for luminaires with compact fluorecent lamps,general illumination,public areas,stairways,corridors,foyers,shops
Item No. | IBDL242 |
Wattage | 9W/15W/20W/30W |
CRI | 80/90 |
CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
Beam angle | 24/45 degree |
Lumen | 990lm/1650lm/2200lm/3240lm |
Finish | Matt white trim |
IP rating | IP20 |
Material | Die-casting alu.trim and heatsink,PMMA lens |
Driver | Constant current remote LED driver included |
Product Size | Φ87*H40mm for 9W Φ106*H45mm for 15W Φ135*H55mm for 20W Φ175*H65mm for 30W |
Cutout size | Φ 75mm for 9W Φ 95mm for 15W Φ 120mm for 20W Φ 160mm for30W |
LED source | COB, Cree/Bridgelux |
Input Voltage | 220-240vac/100-240vac |
Diming | Non Dim/Triac/0-10V/Dali Dim |
